DO, D Fuse Link

Application

This system of Neo D-fuse-links is proper to protect cables and electrical wires at a rated voltage of 380V AC and 250V DC. The fusing-indicators, in several colors, allow to show both the rating and the fusion of the cartridge. A suitable gauger must be inserted in the base and the whole device is blocked by means of the screw cap. In this way we have got a non-interchangeability of the fuselinks with others of different currents.

SPECIFICATION SIZE(MM) D01 D02 D03 DI DII DIII DIV VOLT 380V 380V 380V 500V 500V 500V 500V 2A O O     O     4A O O     O     6A O O     O     10A O O     O     16A O O     O     20A O O       O   25A O O       O   35A     O     O   50A     O     O   63A     O     O   80A       O     O 100A       O     O
