APPLICATION
FC series AC contactor is suitable for using in the circuits up to rated voltage 690V AC 50Hz or 60Hz for making and breaking remote circuits and rated operating current 9A, 12A, 13.5A, 22A, 30A, 37A, 48A, 60A, 75A and 85A at rated operating voltage 380V under utilization category AC-3. It can be combined with suitable thermal overload relays to form electro-mangnetic starters in order to protect overload circuit.
SPECIFICATION
|
Type |
Rated insulated voltage
Ui (V) |
Rated heating current
Ith (A) |
Rated working voltage
Ue (V) |
Rated working current (le) & oper-ating frequency at discontinuous cycle |
AC-3
Pe
(KW) |
Com-bining voltage range
(V) |
Re- leasing voltage range (V) |
|
AC-3 |
|
le
(A) |
Operating
frequency (1/h) |
|
(FC-8) |
690 |
20 |
200~220 |
11 |
1200 |
2.5 |
0.80~1.1
Us (cold ) |
0.20~0.75
Us (cold) |
|
380~440 |
9 |
4 |
|
500~550 |
7 |
4 |
|
(FC-10) |
20 |
200~220 |
13.5 |
1200 |
3.5 |
|
380~440 |
12 |
5.5 |
|
500~550 |
9 |
5.5 |
|
(FC-15) |
20 |
200~220 |
13.5 |
1200 |
3.5 |
|
380~440 |
13.5 |
6.5 |
|
500~550 |
9.5 |
5.5 |
|
(FC-18,19,20) |
40 |
200~220 |
22 |
1200 |
5.5 |
|
380~440 |
22 |
11 |
|
500~550 |
17 |
11 |
|
(FC-24) |
50 |
200~220 |
21 |
600 |
11 |
|
380~440 |
20 |
15 |
|
500~550 |
24 |
15 |
|
(FC-25) |
50 |
200~220 |
39 |
60 |
11 |
|
380~440 |
30 |
18.5 |
|
500~550 |
24 |
18.5 |
|
(FC-30) |
50 |
200~220 |
39 |
600 |
30 |
|
380~440 |
37 |
30 |
|
500~550 |
29 |
30 |
|
(FC-35,40) |
65 |
200~220 |
52 |
600 |
30 |
|
380~440 |
48 |
30 |
|
500~550 |
33 |
30 |
|
(FC-50) |
80 |
200~220 |
65 |
600 |
18.5 |
|
380~440 |
60 |
30 |
|
500~550 |
45 |
30 |
|
(FC-60,65) |
80 |
200~220 |
80 |
600 |
22 |
|
380~440 |
75 |
37 |
|
500~550 |
60 |
37 |
|
(FC-80) |
100 |
200~220 |
85 |
600 |
22 |
|
380~440 |
85 |
45 |
|
500~550 |
70 |
45 |
|
(FC-80S) |
100 |
200~220 |
105 |
600 |
30 |
|
380~440 |
85 |
45 |
|
500~550 |
70 |
45 |
|
(FC-85) |
100 |
200~220 |
105 |
600 |
30 |
|
380~440 |
85 |
45 |
|
500~550 |
70 |
45 |
External & mounting dimension
|
Type |
External dimension (mm) |
Mounting dimension (mm) |
Type of auxiliary contact |
|
L Amax |
W Bmax |
H Cmax |
a |
b |
c |
|
(FC-8,10,15) |
68.6 |
44 |
80 |
34 |
52~56 |
2-M4 |
1NO |
|
(FC-8.10.15) |
68.5 |
54 |
80 |
34 |
48~56 |
2-M4 |
1NO+1NC |
|
(FC-18) |
70 |
65.5 |
84 |
54 |
56~59 |
2-M4 |
1NO+1NC |
|
(FC-19,20) |
70 |
68.4 |
86.5 |
54 |
56~59 |
2-M4 |
2NO+2NC |
|
(FC-8,10,15) |
86.4 |
78.4 |
91.5 |
64 |
58~62 |
2-M4 |
2NO+2NC |
|
(FC-30,35,40,50) |
106 |
94 |
11.2 |
69~75 |
65 |
2-M4 |
2NO+2NC |
|
(FC-60,65,80) |
126 |
106 |
13.6 |
69~75 |
85 |
2-M5 |
2NO+2NC |
|
(FC-80S,85) |
167 |
106 |
137 |
88~92 |
85 |
2-M5 |
2NO+2NC |
|
