APPLICATION

S-N series AC contactors are suitable for AC 50/60HZ, rated voltage up to 660V, mainly used as putting through long distance, breaking circuit and frequently starting or controlling AC motor. It can also be used for counter-connection breaking of squirrel-cage motor in the case of reducing working current.

SPECIFICATION

Type	Capacity of 3 phase squirrel-cage motor AC-3								Rated heating current Ith(A)
	Rated power(KW)				Rated operating current(A)
	20V-240V	380V-440V	550V	660V	220V-240V	380V-440V	500V	660V
S-N10	2.5	4.0	4.0	4.0	11	9	7	5	20
S-N11	3.5	5.5	5.5	5.5	13	12	9	7	20
S-N12	3.5	5.5	5.5	5.5	13	12	9	7	20
S-N20	5.5	11	11	7.5	22	22	17	9	32
S-N21	5.5	11	11	7.5	22	22	17	9	32
S-N25	8.5	14	14	14	30	30	12	12	40
S-N35	12	20	20	20	40	40	17	17	40
