SPECIFICATION

AC contactors			MS-C11TP-TB	MS-C12TP-TB	MS-C15TP-TB	MS-C16TP-TB	MS-C20TP-TB
Suitable thermal overload relays			S-C11L	S-C12L	S-C15L	S-C16L	S-C20L
			TR-12	TR-12	TR-20	TR-20	TR-20
Power of controllable three-phase motor	Rated volume KW(HP) Application category AC-1	200-220V	3(4)		3.7(5)	5.5(7.5)	5.5(7.5)
		380-440V	4(5.5)		5.5(7.5)	11(15)	11(15)
		500-550V	4(5.5)		5.5(7.5)	11(15)	11(15)
	Rated current(A) Application category AC-3	200-220V	12		16	24	24
		380-440V	9		12	21	21
		500-550V	7		10	17	17

AC contactors			MS-C21TP-TB	MS-C30TP-TB	MS-C35TP-TB	MS-C40TP-TB
Suitable thermal overload relays			S-C21L	S-C30L	S-C35L	S-C40L
			TR-20	TR-20TA	TR-20TA	TR-20TA
Power of controllable three-phase motor	Rated volume KW(HP) Application category AC-1	200-220V	5.5(7.5)	7.5(10)	9(12.5)	11(15)
		380-440V	11(15)	15(20)	15(7.5)	22(30)
		500-550V	11(15)	15(20)	5.5(7.5)	22(30)
	Rated current(A) Application category AC-3	200-220V	24	30	35	44
		380-440V	21	27	27	40
		500-550V	17	22	2	32
