APPLICATION
CJX2(LC1-D) series AC contactor is suitable for using in the circuits up to the rated voltage 660V AC 50Hz or 60Hz, rated current 95A, for making,breaking, frequent starting & controlling the AC motor. Combined with the auxiliary contact block, air dealer & machine-interlocking device etc, it becomes the delay contactor, mechanical interlocking contactor, star-delta starter. With the thermal relay, it is combined into the electromagnetic starter.The Contactor is produced according to IEC158-1,VDE0660 & BS 5452.
TECHNICAL DATA
| Type |
LC1-D09 |
LC1-D12 |
LC1-D18 |
LC1-25 |
LC1-D32 |
| Rated working current (A) |
AC3 |
9 |
12 |
18 |
25 |
32 |
| AC4 |
3.5 |
5 |
7.7 |
8.5 |
12 |
| AC3 capacity
of phase 3
squirrel-cage motor
AC3(KW) |
220V |
2.2 |
3 |
4 |
5.5 |
7.5 |
| 380V |
4 |
5.5 |
7.5 |
11 |
15 |
| 415V |
4 |
5.5 |
9 |
11 |
15 |
| 440V |
4 |
5.5 |
9 |
11 |
15 |
| 660V |
5.5 |
7.5 |
10 |
15 |
18.5 |
| Rated heat current(A) |
20 |
20 |
32 |
40 |
50 |
| Electrical life |
AC4X104 |
20 |
20-15 |
20-7 |
15-7 |
15-7 |
| AC3X106 |
2 |
2 |
2 |
2 |
2 |
| Mechanical lifeX106 |
20 |
20 |
20 |
20 |
20 |
| number of the contact |
3P+NO |
| 3P+NC |
| Coil voltage(V) |
24 |
42 |
48 |
110 |
120 |
127 |
220 |
240 |
| Frequency(Hz) |
50 |
B5 |
D5 |
E5 |
F5 |
- |
G5 |
M5 |
U5 |
| 50/60 |
B7 |
D7 |
E7 |
F7 |
- |
G7 |
M7 |
U7 |
| Coil voltage(V) |
380 |
415 |
440 |
480 |
500 |
600 |
660 |
| Frequency(Hz) |
50 |
Q5 |
N5 |
R5 |
- |
S5 |
- |
Y5 |
| 50/60 |
Q7 |
N7 |
R7 |
- |
- |
- |
- |
| Type |
LC1-D40 |
LC1-D50 |
LC1-D65 |
LC1-D80 |
LC1-D95 |
| Rated working current (A) |
AC3 |
40 |
50 |
65 |
80 |
95 |
| AC4 |
18.5 |
24 |
28 |
37 |
44 |
| AC3 capacity
of phase 3
squirrel-cage motor
AC3(KW) |
220V |
11 |
15 |
18.5 |
22 |
25 |
| 380V |
18.5 |
22 |
30 |
37 |
45 |
| 415V |
22 |
25 |
37 |
45 |
45 |
| 440V |
22 |
30 |
37 |
45 |
45 |
| 660V |
30 |
33 |
37 |
45 |
45 |
| Rated heat current(A) |
60 |
80 |
80 |
125 |
125 |
| Electrical life |
AC4X104 |
10-7 |
7 |
7-6 |
7-5 |
7-5 |
2 |
2 |
1.6 |
1.6 |
1.6 |
| Mechanical life 106 |
20 |
20 |
20 |
10 |
10 |
| number of the contact |
3P+NC+NO |
TECHNICAL DATA
|
Type |
LC1-D115 |
LC1-D150 |
LC1-D170 |
LC1-D205 |
LC1-D245 |
LC1-D300 |
LC1-D410 |
LC1-D475 |
LC1-D620 |
|
Rated working current (A) |
380V |
AC3 |
115 |
150 |
170 |
205 |
245 |
300 |
410 |
475 |
620 |
|
AC4 |
52 |
60 |
75 |
85 |
705 |
210 |
138 |
147 |
180 |
|
660V |
AC3 |
86 |
107 |
110 |
130 |
170 |
325 |
305 |
355 |
460 |
|
AC4 |
49 |
61 |
69 |
80 |
90 |
118 |
135 |
145 |
170 |
|
Rated heat current (A) |
250 |
250 |
250 |
275 |
315 |
400 |
500 |
700 |
1000 |
|
AC3 capacity of phase 3 squirrel-cage motor AC3(KW) |
220V |
30 |
40 |
55 |
63 |
75 |
100 |
110 |
147 |
200 |
|
380V |
55 |
75 |
90 |
110 |
132 |
160 |
220 |
365 |
335 |
|
660V |
80 |
100 |
110 |
129 |
160 |
220 |
280 |
335 |
450 |
|
Operation frequency (time/h) |
Electrical life |
AC3 |
600 |
|
AC4 |
150 |
|
Mechanical life |
2400 |
|
AC3 |
60X105 |
50X105 |
30X105 |
20X105 |
|
AC4 |
15X105 |
8 |
5 |
|
Mechanical life |
600X105 |
500 |
|
number of the contact |
RT16-160 |
RT16-250 |
RT16-250 |
RT16-315 |
RT16-315 |
RT16-400 |
RT16-500 |
RT16-630 |
RT16-630 |
|
