Type |
MS-P11PBS |
MS-P12PBS |
MS-P16PBS |
MS-P21PBS |
MS-P25PBS |
|
AC contactors |
S-P11 |
S-P12 |
S-P16 |
S-P21 |
S-P25 |
|
Suitable thermal overload relays |
TH-P12 |
TH-P12 |
TH-P20 |
TH-P20 |
TH-P20(TA) |
|
Motor rated volume |
KW |
HP |
A |
KW |
HP |
A |
KW |
HP |
A |
KW |
HP |
A |
KW |
HP |
A |
|
Equivalently conformto CNS C4048 JIS C8325 Application category Class Ac3 rated volume |
1phase |
100~110V |
0.55 |
0.75 |
12 |
0.55 |
0.75 |
12 |
0.75 |
1 |
16 |
1.1 |
1.5 |
24 |
1.1 |
1.5 |
24 |
|
200~220V |
1.1 |
1.5 |
12 |
1.1 |
1.5 |
12 |
1.5 |
2 |
16 |
2.2 |
3 |
24 |
2.2 |
3 |
24 |
|
3phase |
200~220V |
3 |
4 |
12 |
3 |
4 |
12 |
3.7 |
5 |
16 |
5.5 |
7.5 |
24 |
6.5 |
8.5 |
26 |
|
380~440V |
4 |
5.5 |
9 |
4 |
5.5 |
9 |
5.5 |
7.5 |
12 |
11 |
15 |
21 |
12 |
16 |
23 |
|
500~550V |
4 |
5.5 |
7 |
4 |
5.5 |
7 |
5.5 |
7.5 |
10 |
11 |
15 |
17 |
12 |
16 |
20 |
|
Equivalently conformto IEC 60947-4-1 EN60947-4-1 Application category Class Ac3 |
3
phase |
240V |
3.5 |
4.5 |
13 |
3.5 |
4.5 |
13 |
4.5 |
6 |
18 |
5.5 |
7.5 |
24 |
6.5 |
8.5 |
16 |
|
440V |
5.5 |
7.5 |
12 |
5.5 |
7.5 |
12 |
7.5 |
10 |
16 |
11 |
15 |
21 |
12 |
16 |
24 |
|
550V |
5.5 |
7.5 |
9 |
5.5 |
7.5 |
9 |
7.5 |
10 |
13 |
11 |
15 |
17 |
12 |
16 |
17 |
|
660V |
5.5 |
7.5 |
7 |
5.5 |
7.5 |
7 |
7.5 |
10 |
9 |
11 |
15 |
14 |
12 |
16 |
28 |
|
UI508 CSA-C22.2 Rated colume |
1phase |
100~110V |
|
0.5 |
9.8 |
|
0.5 |
9.8 |
|
1 |
16 |
|
2 |
24 |
|
2 |
21 |
|
200~220V |
|
2 |
12 |
|
2 |
12 |
|
3 |
17 |
|
3 |
17 |
|
3 |
17 |
|
3phase |
200~220V |
|
3 |
9.6 |
|
3 |
9.6 |
|
5 |
15.2 |
|
7.5 |
22 |
|
10 |
28 |
|
380~440V |
|
7.5 |
11 |
|
7.5 |
11 |
|
10 |
14 |
|
15 |
21 |
|
15 |
21 |
|
500~550V |
|
10 |
11 |
|
10 |
11 |
|
10 |
11 |
|
15 |
17 |
|
15 |
17 |
|
Auxiliary contact of AC contactor |
Standard |
1a(1NO) |
1a1b(1NO1NC) |
1a1b(1NO1NC) |
1a1b(1NO1NC) |
1a1b(1NO1NC) |
|
Especial |
1b(1NC) |
2a(2NO) |
- |
- |
- |
|
Auxiliary contact of thermal overload relay |
1a1b(1NO1NC) |
1a1b(1NO1NC) |
1a1b(1NO1NC) |
1a1b(1NO1NC) |
1a1b(1NO1NC) |
