Product description and
technical parameters: |
A selector switch is built into the instrument for measurement of AC Ammeter in a three phase network.
Model: BS-96 BS-72
Accuracy: class 1.5
Frequency: 50Hz
Measuring range: 0.1A/1A, 0.2A/2A, 0.3A/3A, 0.4A/4A, 0.5A/5A, 1A/15A , 5A/5A
3-Position: L1-L2,L1-L3,L2-L3(OFF-Position is available on request).
AC ammeters with 3-Position selector switch can be used for the measurement of AC current in three phase three wire system and three phase four wire system.
Case: Non-combustile ABS plastic material is used for making external case. Mounting: flush mounting with bracket, the maximum mounting depth is 43 mm. |
